Designing a 4 BHK building in AutoCAD and estimating the required materials involves several steps. Here’s a structured guide:
—
1. Create a 4 BHK Building Sketch in AutoCAD
Step 1: Set Up AutoCAD
Open AutoCAD and set up the units (meters, feet, or millimeters).
Use the LAYERS feature to separate walls, doors, windows, plumbing, and electrical layouts.
Step 2: Draw the Basic Floor Plan
Use the LINE or POLYLINE tool to draw the outer and inner walls.
Keep room dimensions as per your requirement, e.g.,
Master Bedroom: 12×14 ft
Other Bedrooms: 10×12 ft
Living Room: 14×18 ft
Kitchen: 10×10 ft
Bathrooms & Balcony
Step 3: Add Details
Use the DOOR and WINDOW tools to insert openings.
Add furniture blocks (AutoCAD blocks) for a better visual representation.
Mark plumbing and electrical points with respective layers.
Step 4: Elevation & Section Views
Use 3D modeling tools (EXTRUDE, PRESSPULL) for elevation.
Draw cross-sections to understand the structural components.
—
2. Material Estimation for Construction
Foundation & Structure
Cement: ~350-400 bags
Steel (TMT bars): ~3-5 tons
Sand: ~1500-2000 cubic feet
Aggregates: ~2000-2500 cubic feet
Bricks/Blocks: ~30,000-35,000 pieces
Walls & Plastering
Bricks: 9-inch for outer walls, 4-inch for partitions
Cement Mortar for plastering
Roofing & Flooring
RCC Slab: Concrete mix M20 or M25
Tiles/Marble/Granite: Depending on choice (~1200-1500 sqft)
Doors, Windows, and Paint
Doors: Wood, Aluminum, or PVC (~6-8 doors)
Windows: Glass or Aluminum (~8-12 windows)
Paint: Interior & Exterior (~150-200 liters)
Electrical & Plumbing
Wiring, Switches, and Lights
Pipes, Sanitaryware, and Fittings
—
3. Cost Estimation (Approx.)
Basic Construction: ₹1,500-₹2,500 per sq. ft (India)
Luxury Construction: ₹2,500-₹5,000 per sq. ft
—
Would you like a detailed AutoCAD floor plan file or any specific customization for your 4 BHK layout?
